The TC-1 takes the best parts of timecode box units from the past and brings them all together into a timecode generator built for the future. Deity has developed it to fit into your workflow, no matter how you work. You can wirelessly jam it from your phone or even wirelessly sync it from other boxes using Deity's proprietary 8 channel 2.4G radio ecosystem. You can also hardwire jam it or use it to internally generate timecode and jam other devices.
Long Range Wireless Control
Using Deity's exclusive Bit Connectify technology you can control up to 20x TC-1 wireless timecode generator boxes from 250 ft away. The TC-1 has 600% more control range than Bluetooth timecode boxes from leading competitors.
The TC-1 also features a secondary RF chip for syncing TC-1 to TC-1 devices from a range of 30 ft. When syncing the timecode from the phone, you can transmit up to 250 ft to the master TC-1 and then 30 ft to each other TC-1 timecode boxes around the master node.
Frame Accurate Timecode
Each TC-1 timecode generator box features a TCXO with an accuracy of ±0.5ppm. And through firmware optimization, your footage will sync perfectly when you go to edit with less than 1 frame of drift in a 72-hour period.
Locking 3.5 mm TC Connection
You won't have to worry about your TC cables getting unplugged with the TC-1. The port is also compatible with other brands' non-locking 3.5 mm TC cables.
Timecode Makes Post Easier
With more devices than ever now supporting SMPTE timecode, syncing footage and audio in post has never been so easy or quick. With the TC-1 and other items (like the BP-TRX and the TC-SL1) you can use the workflow methods used by studio feature films.
Built In Scratch Mic
The TC-1 timecode box features an on-board scratch microphone for when you're using a Mirrorless or Action Camera the only feature a stereo mic input.
SIDUS Audio App
Connect all your devices to your phone or laptop via SIDUS Audio. With the app, you can control your device's settings, monitor its status, and sync all your units at once.
Specifications | |
Capacity | Timecode SMPTE High Frame Rates Frame Rates 23.98/24/25/29.97/29.97DF/30/50/60 fps Timecode Accuracy ±0.5ppm Timecode Ports Locking 3.5mm Output Types 2.5Volt TC Line Level Mic Level (+Scratch Mic) Audio Built-In Scratch Mic Wireless Type 2.4G RF Bluetooth® 5 RF Channels 8 Display Type 1" OLED Display Battery Type Lithium-ion Rechargable Battery Battery Charger USB-C Battery Capacity 950mAh Battery Life Upto 28Hrs Built-In Microphone Omni-Directional TC-1 Net Weight 41g TC-1 Dimensions 53.4 * 40 * 21.8mm Temperature Range -20°C to +45°C |
